Topic file parameters

Topic files are used to define configuration for individual topics.

The following example is a high-level look at the possible parameters in a topic file. Refer to individual sections for more information about each parameter's uses and accepted values.

# Defines the base view for the topic
base_view: <view_name>

# Defines the workbook display name of the base view when it's accessed from the topic
base_view_label: <Some Display Name>

# Limits access to rows based on user attributes
access_filters:
- field: <view_name>.<field_name>
user_attribute: <user_attribute>
values_for_unfiltered: [<value_1>, <value_2>, ...]

# Information that provides context to the AI Query Helper
ai_context: <some information>

# Inserts a non-removable filter into the WHERE clause of the generated SQL block of all queries in the topic
always_where_sql: ${<view_name>.<field_name>} <condition>

# Forces all queries using the topic to require a run click to return new results
auto_run: true

# Defines the cache policy for the topic
cache_policy: <cache_policy>

# Defines a removable filter that's applied to all rows in a topic
default_filters:
<view_name>.<field_name>:
<filter_conditions>

# Description of the topic, which will display in the workbook
description: <brief summary>

# Determines the order in which the topic displays
display_order: <integer>

# Curates the fields available in the topic
fields: [all_views.*]

# Defines the group the topic belongs to; useful for organizing multiple topics in a model
group_label: <group name>

# Removes the topic from the workbook
hidden: false

# Declares other views as part of the topic
joins:
<view_name>: {}

# Defines a display name for the topic, which will be visible in the workbook
label: <topic display name>

# Defines a list of topic-level joins
relationships:
- join_from_view: <view_one>
join_to_view: <view_two>
join_to_view_as: <name_of_view>
join_type: always_left
on_sql: ${<name_of_view>.id} = ${<view_one>.some_id}
relationship_type: many_to_one

# Defines a list of access grants to apply to the topic
required_access_grants: <access_grant_name>

# Allows customization of views only in the context of the topic
views:
<view_name>:
<customization>

access_filters:

Limits access to rows based on user attributes. When enabled, users will be limited to rows in the topic that match their user attribute value.

To allow specific users to access all data for a field, add the values_for_unfiltered parameter. Users with this user attribute value will not have the access filter applied, allowing them to access all data for the specified field.

Note: Omni expects every user to have a non-null value for any assigned access filter. Errors will arise if the user attribute value is null.

access_filters:
- field: products.brand # Required. Defines the field to use as a filter.
user_attribute: brand_id # Required. The user attribute to filter on.
values_for_unfiltered: [is_admin] # Optional. User attribute value to allow unrestricted access.

ai_context:

Free text that can provide context to the AI Query Helper. This could include:

  • Behavioral prompting:

    ai_context: |
    you are the head of finance. you are concerned with the status of customer payments. you often need to project into the future how many invoices are due and for how much. you also need to know if any invoices are late so you can reach out to those customers.
  • Example queries and structured Omni query results:

    ai_context: |
    question: which customers are behind due on payment?

    answer:

    {
    "limit": 1000,
    "sorts": [
    {
    "column_name": "share_rillet_omni_omni__invoices.due_date",
    "sort_descending": true,
    "is_column_sort": false,
    "null_sort": "OMNI_DEFAULT"
    }
    ],
    "table": "share_rillet_omni_omni__invoices",
    "fields": [
    "share_rillet_omni_omni__invoices.customer_id",
    "share_rillet_omni_omni__invoices.customer_name",
    "share_rillet_omni_omni__invoices.invoice_number",
    "share_rillet_omni_omni__invoices.due_date",
    "share_rillet_omni_omni__invoices.total_amount"
    ],
    "pivots": [],
    "dbtMode": false,
    "filters": {
    "share_rillet_omni_omni__invoices.due_date": {
    "is_negative": false,
    "kind": "BEFORE",
    "right_side": "today",
    "type": "date",
    "ui_type": "BEFORE"
    },
    "share_rillet_omni_omni__invoices.status": {
    "type": "string",
    "kind": "EQUALS",
    "values": [
    "unpaid"
    ],
    "is_negative": false,
    "case_insensitive": true
    }
    },
    "modelId": "aeb6f3f4-b0e5-4abb-97eb-eaeb42a16944",
    "version": 5,
    "rewriteSql": true,
    "row_totals": {},
    "fill_fields": [],
    "calculations": [],
    "column_limit": 50,
    "join_via_map": {},
    "column_totals": {},
    "userEditedSQL": "",
    "dimensionIndex": 0,
    "default_group_by": true,
    "join_paths_from_topic_name": "invoices"
    }

always_where_sql:

Inserts a filter into the WHERE clause of the generated SQL block of all queries in the topic. Users with the Querier role can't change this filter and it will be visible only in the underlying SQL of any queries. This filter is additive to any filters specified in the workbook. For optional filter conditions, use default_filters.

This parameter is useful for removing invalid data from the topic, such as deleted records or internal testing.

Conditions should be written using mustache (${}) syntax.

Did you know?

You can generate a syntactically correct condition using the workbook:

  1. In a workbook, add the filter using the UI.
  2. Click the SQL button near the top-right corner of the page.
  3. Copy the content of the WHERE clause.

Then, you can paste it right into the always_where_sql parameter!

base_view: order_items
always_where_sql: ${order_items.sale_price} != 0

auto_run:

Forces all queries using the topic to require a run click to return new results. Note: This will override the model-level auto_run parameter.

auto_run: false # Accepted values are true or false

base_view:

Defines the base view for the topic. Values should be unquoted. Quotes will be removed/ignored upon saving.

base_view: users

# Use <schema>__<view> to specify a schema
base_view: main__users

base_view_label:

Defines the display name of the table in the workbook when it is accessed from the topic. This can be helpful for conveying the table's meaning in a specific context.

For example, the order_items view can be referred to as Sold Items in a financial context, which could help a Finance team understand that the table contains sale records.

base_view: order_items
base_view_label: Sold Items # Values should be unquoted. Quotes will be removed/ignored upon saving.

cache_policy:

Defines the cache policy for the topic. The value should be a cache policy defined in the topic's model (cache_policies).

cache_policy: daily_cache_policy

default_filters:

Applies a filter to all rows in a topic. Filters created using this parameter are visible in workbooks and can be removed by users. For required filter conditions, use always_where_sql.

Refer to the Filters documentation for filter examples and syntax details.

default_filters:
users.state:
is: California

description:

Free text that describes the table. For example, you could add copy that describes the type of analyses users can create using the topic.

Descriptions are visible in the workbook, specifically in the topic switcher of the Fields & Topics panel.

Values should be unquoted. Quotes will be removed/ignored upon saving.

# Single line description
description: All transactions related to orders from the online store.

# Multi-line description
# Use this approach to include colons ( : )
description: |
Transactions from: California, Washington, and Oregon

display_order:

Defines the order that topics display in the field picker. By default, topics are sorted alphabetically. Defining a display_order will override this default for the topic.

The value must be a whole number, such as 1, 2, and so on.

display_order: 3

extends:

Coming soon.

fields:

Curates the fields available in the topic. By default, all fields from the base view and joined views are included in the topic.

This parameter supports the following operators:

OperatorDescriptionOrder of operations
all_views.*Targets all fields from all views in the topic1
view.*Targets all fields in a view2
tag:<value>Targets fields and views with the specified tag3
view.fieldTargets a specific field4

Omni will evaluate the operators according to the Order of operations value in the above table. This means all views is evaluated first, then specific views, and so on. This allows you to exclude views and then add specific fields back in.

To exclude a view, tag, or field, prefix the clause with a -. For example: -users.*

# Include only the users view
fields: [users.*]

# Exclude the users view
fields: [all_views.*, -users.*]

# Exclude only the users.id field
fields: [all_views.*, -users.id]

# Exclude fields with the `pii` tag
fields: [all_views.*, -tag:pii]

# Add the user_facts.lifetime_value back in after excluding the user_facts view
fields: [all_views.*, -user_facts.*, user_facts.lifetime_value]

# Remove the users.acquisition_cost field from the fields targeted by the marketing tag
fields: [-all_views.*, tag:marketing, -users.acquisition_cost]

group_label:

Defines the group the topic belongs to. This is useful for improving the organization and navigation of topics in workbooks or the IDE. For example, you could create group topics together by dataset (Salesforce), team (Marketing), or analytical area (Product usage).

Note: Topics without a group_label will display as 'ungrouped' below topic groups in the topic switcher.

group_label: Marketing # Values should be unquoted. Quotes will be removed/ignored upon saving.

hidden:

Removes the topic from the workbook. The topic can still be referenced in the model.

hidden: true  # Value must be true or false

joins:

Declares other views as part of the topic. To include multiple tables, nest the table under the table it joins through.

Note: The final table in each node - specifically, those without children - requires an empty bracket pair {}

joins:
inventory_items: # Includes inventory_items in the topic
products: # Joins products to inventory_items
distribution_centers: {} # Joins distribution_centers to products
users: {} # Includes users in the topic

label:

Defines a display name for the topic. This will override the topic's name as it displays in the workbook.

Values should be unquoted. Quotes will be removed/ignored upon saving.

label: California

relationships:

Defines a list of topic-level joins. Joins defined using this parameter will only be available to the topic where they are declared. This can be useful for one-off use cases, rare aliasing, or utilizing different join organization schemes. Refer to the Relationships & Joins documentation for more information about top-level and global relationships.

The syntax for this parameter is identical to that of the relationships file.

topics:
order_items:
joins:
buyers: {}
sellers: {}
relationships:
# Join order_items to users as buyers using order_items.buyer_id
- join_from_view: order_items
join_to_view: users
join_to_view_as: buyers
join_type: always_left
on_sql: ${buyers.id} = ${order_items.buyer_id}
relationship_type: many_to_one

# Uses user attributes ({{ omni_attributes.<user_attribute> }}) to create an access filtered join
# This can be useful when you want to keep all rows in the data set but permiss the metadata

# This example will only return data for the specific seller_org_id associated with each user
- join_from_view: order_items
join_to_view: users
join_to_view_as: sellers
join_type: always_left
on_sql: ${sellers.id} = ${order_items.seller_id} AND ${sellers.organization_id} = {{ omni_attributes.seller_org_id }}
relationship_type: many_to_one

# Another single-use example
# Note this from is not aliased in the context of the join,
# but connection is implied by nesting in topic above
relationships:
- join_from_view: users
join_to_view: user_attributes
join_to_view_as: seller_attributes
join_type: always_left
on_sql: ${users.id} = ${seller_attributes.user_id}
relationship_type: one_to_one

required_access_grants:

Defines a list of access grants to apply to the topic. This setting is used to restrict access to the topic.

The values of this parameter must match the name of an access grant in the model file. For example, this defines a region_access policy in a model file:

Model file
access_grants:
region_access:
user_attribute: "Region"
allowed_values: ["California", "Hawaii"]

Then, in the topic file, required_access_grants is used to apply the access grant:

Topic file
required_access_grants: [region_access]

Refer to the Data access control guide for more information and examples.

template:

Coming soon.

views:

Allows customization of views only in the context of the topic. For example, you can use this parameter to:

  • Create aliases for joins between tables in the topic. When aliasing a join for a specific topic, often topic-specific relationships are the best way to model, field names may also be adjusted or renamed or relabeled (see above).
  • Define topic-specific drilling
  • Define topic-specific aggregate awareness
# Defines the order in which views in the topic display
views:
order_items:
display_order: 1
users:
display_order: 2
products:
display_order: 3
Extended example

The following example customizes the opp_line_item_daily_facts view to analyze metrics at different points in a contract's lifecycle (start, now, end).

Custom, context-specific names are applied to the drr_sum and arr_sum measures to analyze the metric at each point in the life cycle. For example, Starting ARR and Current ARR.

Then, topic-specific joins are used to apply different dates - such as a contract start or end date - and create views specific to each point of the contract lifecycle.

views:
# First extension; focuses on contract start
opp_line_item_start_facts:
extends: [ opp_line_item_daily_facts ]

dimensions:
drr_sum:
label: Starting DRR # Topic-specific name for the drr_sum base metric

arr_sum:
label: Starting ARR # Topic-specific name for the arr_sum base metric

measures: # Creates a Starting ARR Sum measure
arr_sum_sum:
sql: ${opp_line_item_start_facts.arr_sum}
label: Starting ARR Sum
aggregate_type: sum

# Second extension; focuses on current contract state
opp_line_item_current_facts:
extends: [ opp_line_item_daily_facts ]

dimensions:
drr_sum:
label: Current DRR

arr_sum:
label: Current ARR

measures:
arr_sum_sum:
sql: ${opp_line_item_current_facts.arr_sum}
label: Current ARR Sum
aggregate_type: sum

# Third extension; focuses on contract end
opp_line_item_end_facts:
extends: [ opp_line_item_daily_facts ]

dimensions:
drr_sum:
label: Ending DRR

arr_sum:
label: Ending ARR

measures:
arr_sum_sum:
sql: ${opp_line_item_end_facts.arr_sum}
label: Ending ARR Sum
format: USDCURRENCY_0
aggregate_type: sum

### Topic-specific joins of the same fact table but with different dates
### to understand ARR at different points of the contract lifecycle (start, now, end)
relationships:
- join_from_view: opp_line_item_facts
join_to_view: opp_line_item_start_facts
join_type: always_left
on_sql: ${salesforce__opportunity.id} = ${opp_line_item_start_facts.opp_id} AND
${opp_line_item_start_facts.date} =
${opp_line_item_facts.oli_first_date}
relationship_type: one_to_one

- join_from_view: opp_line_item_facts
join_to_view: opp_line_item_end_facts
join_type: always_left
on_sql: ${salesforce__opportunity.id} = ${opp_line_item_end_facts.opp_id} AND
DATEADD(day, 1, ${opp_line_item_end_facts.date}) =
${opp_line_item_facts.oli_last_date}
relationship_type: one_to_one

- join_from_view: opp_line_item_facts
join_to_view: opp_line_item_current_facts
join_type: always_left
on_sql: ${salesforce__opportunity.id} = ${opp_line_item_current_facts.opp_id}
AND ${opp_line_item_current_facts.date[date]} = CURRENT_DATE()
relationship_type: one_to_one
